'07-18 Chevy/GM 1500 2wd/4wd FOX 2.5 Factory DSC Kit
'07-18 Chevy/GM 1500 2wd/4wd FOX 2.5 Factory DSC Kit
MCQUEEN
190 South McQueen Road
Suite 109
Gilbert AZ 85233
United States
If you want the best in performance and style for your Chevy 1500, the FOX 2.5 DSC coil-over kits are the way to go. These give you the ability to lift and vastly improve the ride quality both on and off-road. Each coil-over is designed to gain maximum wheel travel with an aftermarket upper arm all while keeping CV joints, tie rods, uni-balls and ball-joints in their working ranges. FOX’s have a 2.5″ diameter shock body for added oil capacity for aggressive use both on and offroad. Based on their race shocks, they are fully rebuild-able and revalve-able for optional tuning and maintenance. The remote external reservoirs increase the oil capacity for lower operating temperatures and the Dual Speed Compression (DSC) adjuster gives remarkable versatility and precise tuning. A simple twist of either two adjuster knobs allows twelve separate low-speed and ten high-speed compression levels. The integrated coil spring can be adjusted for preload and ride height and comes pre-set to level your vehicle right out of the box.
After lifting your truck, the stock upper arms become the limiting factor and hold back your suspensions performance. Our uniball upper arms address these issues and more. Replacing the stock ball-joint with a uni-ball bearing, we can increase wheel travel with a part that is considerably stronger and will last longer under extreme conditions. We also engineered the arms with more caster and changed the camber curve to correct geometry so the vehicle aligns correctly and improves driving characteristics and handling.
In the rear we go with a pair of FOX’s 2.5 Factory DSC Series shocks for increased damping and control.
WHAT'S INCLUDED:
- FOX Factory Series 2.5 DSC Coilovers (880-06-525)
- Camburg 1.25 Uniball Upper Arms (CAM-210051)
- FOX Factory Series 2.5 DSC Rear Shocks (883-26-003)
FRONT COILOVER FEATURES:
- 2.5″ Smooth bore and honed seamless alloy bodies
- Zinc-plated and double-clear coated for long lasting finish
- 2.5″ Smooth bore 6061-T6 Aluminum is hard anodized black reservoir
- Eibach® racing springs
- 7/8″ hardened NitroSteel® Steel carbon shafts
- 6061-T6 hard-anodized, high flow aluminum pistons
- PTFE-lined, heat-treated, alloy steel spherical bearings
- Made in the USA
SPECS:
Lift | Track Width | Wheel Size | Max Backspacing | Tire Size |
---|---|---|---|---|
0-3 in (front) | Stock | 16-17 in | 4.75 in | 32-33 in |
