Rigid Industries
Adapt E-Series LED Light Bar
Bar Length (in.)
Adapt E-Series LED Light Bar
20"
MCQUEEN
190 South McQueen Road
Suite 109
Gilbert AZ 85233
United States
The RIGID Adapt E-Series LED Light Bar features the same style and construction as RIGID’s legendary E-Series, from the high-strength aluminum heat sink to the unbreakable polycarbonate lens. On the inside, however, the Adapt E-Series contains cutting-edge technology. The Adapt E-Series takes off-road lighting performance to a whole new level with two layers of adaptive response to your vehicle and driving conditions.
KEY FEATURES:
- Harness, Switch & Relay Included
- 3 Optic Zones - Scene, Driving, Spot
- Seamless Beam Transition
- Slow Speed, Moderate Speed & High Speed Beam Patterns
- 9-36 VDC
- Two Layers of Adaptive Response
- Active Power Management™ System - Power Capacity Sensing
- Active View Technology™ - Internal GPS Module
- Use In Adapt Mode Or All On
- Limited Lifetime Warranty
- Alloy Housing and Heatsink
- Unbreakable Polycarbonate Lens
- Pressure Equalizing Vent
- Black Exposed Printed Circuit Board
- Patented Optics
- 50,000 Hr+ LED Lifespan
- Off Road Use Only
WHAT'S INCLUDED:
- Stainless Steel Mounting Brackets
- Hardware Kit
- Wire Harness
- Relay
- Switch
- Install Instructions
SPECS:
Size | Part No. | Wt (Lbs) | Watts | Voltage Max | *Raw Lumens | Lux @ 10m | Beam Distance @1Lux | Beam Distance @.25Lux | **Peak Beam Ibntensity(cd) | Horizontal Beam Angle |
---|---|---|---|---|---|---|---|---|---|---|
20" | 260413 | 6.00 | 97.00 | 36 | 11968 | 3106.00 | 557.00 | 1115.00 | 310578 | 17.00 |
30" | 270413 | 8.00 | 170.00 | 36 | 20944 | 5364.00 | 732.00 | 7165.00 | 536407 | 17.00 |
40" | 280413 | 10.00 | 231.00 | 36 | 29920 | 7425.00 | 862.00 | 1723.00 | 742460 | 17.00 |
50" | 290413 | 13.00 | 358.00 | 36 | 38896 | 9398.00 | 969.00 | 1939.00 | 939827 | 17.00 |
